Onduleur hybride biphasé SANDISOLAR 7,2KW
Modèle: SD-4872WP-US
It is a versatile 7.2kW split-phase hybrid inverter for the US market, featuring dual-channel MPPT with 16A per channel, support for up to 6 Unités en parallèle (configurable for split-phase, single-phase, or three-phase systems), and UPS-level 10ms switching time. It delivers 7200W rated output with 10800VA peak power, accepts up to 150A battery charging current, operates with or without batteries, supports diesel generator input and CT zero-export functionality, and offers intuitive touchscreen control, Diagnostic à distance, and OTA updates—all while complying with UL1741 and FCC standards.
-
Caractéristiques clés et visuels
-
-
Faits saillants
-
- Dual MPPT design improves solar efficiency with 7200W rated output and 10800VA peak power.
- Supports jusqu’à 6 units in parallel for flexible single-phase, split-phase, and three-phase systems.
- 10ms UPS-level switching ensures seamless backup during power outages.
- Battery-free operation and diesel generator compatibility enable flexible system design.
- Smart features include touchscreen control, remote monitoring, Mises à jour OTA, and CT zero export control.
- Supports 4HP motor loads and complies with UL1741 and FCC standards.
Demandez un devis
Télécharger la brochure
Avantages fondamentaux
Haute efficacité
Dual MPPT design improves solar energy utilization.
Puissance élevée
7200W rated and 10800VA peak capacity.
Évolutivité du système
Supports jusqu’à 6 units in parallel expansion.
Commutation rapide
10ms UPS-level seamless transfer.
Flexible Energy System
Works with or without battery storage.
Certified Reliability
Complies with UL1741 and FCC standards.
Spécifications du produit
AC Mode
| Tension d’entrée nominale | 120V (L1/N, L2/N) / 240Vac (L1/L2) | Plage de tension phase d’entrée | (85Vac ~ 140Vac) ±2 % |
| Fréquence | 50Hz / 60Hz (Détection automatique) | Plage de fréquences | 47±0,3Hz ~ 55±0,3Hz (50 Hz); 57±0,3Hz ~ 65±0,3Hz (60Hz) |
| Surcharge / Protection contre les courts-circuits | Disjoncteur | Efficacité | >95 % |
| Temps de conversion (Déviation & onduleur) | 10MS (typique) | AC Reverse Protection | Oui |
Voir le document complet
Application
This 7.2KW split phase hybrid inverter is designed for residential, small commercial, and off-grid energy storage systems. Il fournit une alimentation de secours fiable, flexible system expansion, and intelligent energy management for solar self-consumption, zero-export grid-tied applications, and generator-hybrid power systems.
